Rotary table Bison type 5859-500

€11,725.60 *
€13,953.46 incl. VAT

Prices plus VAT plus shipping costs

Delivery time upon request

  • 375859060000
  • 84663000
  • 302 kg
  • 0
Rotary table Bison 5859-500 - horizontal / vertical rotary table - due to the three dividing... more
Product information "Rotary table Bison type 5859-500"

Rotary table Bison 5859-500

- horizontal / vertical rotary table
- due to the three dividing plates, division into the required
  number of sections is obtained with an accuracy of 1’
- dividing means of graduated drum with 1’30’’
- centering morse taper sleeves are haedened  and ground,
  extending machine life
- depending on the size gear ratio is 1:120
- incl. 3 dividing plates with clamping bolts, slot nuts
  and table lever
